Casting
Overview
Casting is a precision process. It offers tremendous freedom of design. The wide range of possible alloys makes economic solutions possible for the most varied of applications.
Services
- Mold and casting design
- CAD design and simulation (mold filling and solidification)
- Design and procurement of pattern
- Production without pattern (mold milled)
- Procurement of printed molds and cores
- Production of finish parts and assemblies
- Engineering and retrofit (scanning of old condition, CAD, pattern, production and new casting)
- Analysis and special tests of castings and materials
- Measure technique
- Scanning of pattern and castings
Applications
- Automotive
- Aerospace
- Energy
- Maritime
- Industrial Components
- Medical
- Pumps
- Arts
| Copper Alloys | |
| Copper Alloys | max. unit weight (kg) |
| Copper Aluminium | 8,000 |
| Copper Zinc | 2,500 |
| Copper Chromium | 400 |
| Copper Tin Zinc | 100 |
| High-alloy Steel | 2,500 |
| Nickel Based Alloys | 300 |
| Forming Technology | |
| Permanent mold | Permanent mold |
| Continous Casting | ø 120 - 620 mm max. length 2400 mm |
| Centrifugal Casting (CuAl and CuZn) |
ø 120 - 640 mm max. 800 mm |
| Forming Technology | |||
| Dead-mold | Cu Alloys | High-alloy Steel | Ni Based |
| Sand Casting | 1 - 8,000 kg | 1 - 2,500 kg | 1 - 300 kg |
| Ceramic Mold Casting | 1 - 10 kg vacuum casting |
1 - 2,500 kg | 1 - 70 kg |
| Shell Mold Casting | 1 - 10kg | 1 - 10 kg | |
